Solar Pump Inverter

Key Features

Intelligently adjust the working voltage of the solar panel, so that the solar panel always works at the maximum power point of the V-A characteristic curve. The maximum power point tracking(MPPT) function design, the power of the component can reach 96%-99%; One-time input is maintenance-free; Compared with diesel power pumping, it has a higher return on investment.

Solar Pump Production Function

Dry run, low frequency, low power,dormancy,water full ,pump over current production.

Basic Production Function

Bus overvoltage, under voltage, inverter over current,module fault,inverter overload,motor overload,current detection zero ,drift fault.Hall fault,motorgrounding short circuit fault, input phase loss, output phase loss,inverteroverheat,communication fault, motor parameter self-tuning fault.

Motor Grouding Short-circuit Detection

Automatically detect whether the motor is short-circuit to ground, Auto detection while electrify.

Servo Control

Support synchronous and asynchronous servo control.

Communication Network

Support 485/Modbus protocol,CANopen protocol;can realize the network ,linkage control among EPSIVO inverters.

Remote and Monitoring Functions

Support remote program upgrade,remote monitoring ,and remote lock function, can be connected to EPSIVO GPRS module.

Solar Pump Inverter

220V Series/380V Series


AC input: 200V ~ 250V DC(solar) input: 380V < Voc 310V Output: AC 3PH 0 ~ 220V4
AC input: 360V ~ 460V DC(solar) input: 660V < Voc 540V Output: AC 3PH 0 ~ 380V
99.99%
4T: 3PH 380V; 2S:220V
0～60HZ
97%
Forced air cooling
IP65
1000m and below,higher than 1000m,please Please reduce the carrying capacity according to the ratio of 1% per 100 m.
